Once you’re on a tenting journey, you may need to pack your individual meals and perhaps one thing to filter or deal with water that you just discover. However think about your campsite is in house, the place there’s no water, and packing jugs of water would take up room when each inch of cargo house counts. That’s a key problem engineers confronted when designing the Worldwide House Station (ISS).
Earlier than NASA developed a sophisticated water recycling system, water made up almost half the payload of shuttles touring to the ISS. I’m an environmental engineer and have carried out analysis at Kennedy House Heart’s House Life Sciences Laboratory. As a part of this work, I helped to develop a closed-loop water restoration system.
Right this moment, NASA recovers over 90% of the water utilized in house. Clear water retains an astronaut crew hydrated, hygienic, and fed, as it might use it to rehydrate meals. Recovering used water is a cornerstone of closed-loop life help, which is important for future lunar bases, Mars missions, and even potential house settlements.
A detailed-up view of the water restoration system’s racks – these comprise the {hardware} that gives a relentless provide of fresh water for 4 to 6 crew members aboard the ISS. [Photo: NASA]
NASA’s environmental management and life help system is a set of apparatus and processes that carry out a number of features to handle air and water high quality, waste, atmospheric stress, and emergency response programs reminiscent of fireplace detection and suppression. The water restoration system—one element of environmental management and life help—helps the astronauts aboard the ISS and performs a central position in water recycling.
Water programs constructed for microgravity
In microgravity environments just like the ISS, each type of water accessible is efficacious. The water restoration programs on the ISS acquire water from a number of sources, together with urine, moisture in cabin air, and hygiene—that means from actions reminiscent of brushing enamel.
On Earth, wastewater contains varied varieties of water: residential wastewater from sinks, showers and bogs; industrial wastewater from factories and manufacturing processes; and agricultural runoff, which incorporates fertilizers and pesticides.
In house, astronaut wastewater is way more concentrated than Earth-based wastewater. It incorporates considerably larger ranges of urea—a compound from urine—salts, and surfactants from soaps and supplies used for hygiene. To make the water protected to drink, the system must take away all of those shortly and successfully.
The water restoration programs utilized in house make use of among the identical ideas as Earth-based water remedy. Nonetheless, they’re particularly engineered to perform in microgravity with minimal upkeep. These programs additionally should function for months and even years with out the necessity for alternative components or hands-on intervention.
NASA’s water restoration system captures and recycles almost all types of water used or generated aboard the house station. It routes the collected wastewater to a system known as the water processor meeting, the place it’s purified into protected, potable water that exceeds many Earth-based consuming water requirements.
The water restoration and remedy system on the ISS consists of a number of subsystems.
Recovering water from urine and sweat
The urine processor meeting recovers about 75% of the water from urine by heating and vacuum compression. The recovered water is shipped to the water processor meeting for additional remedy. The remaining liquid, known as brine, nonetheless incorporates a major quantity of water. So, NASA developed a brine processor meeting system to extract the ultimate fraction of water from this urine brine.
Within the brine processor meeting, heat, dry air evaporates water from the leftover brine. A filter separates the contaminants from the water vapor, and the water vapor is collected to change into consuming water. This innovation pushed the water restoration system’s total water restoration fee to a powerful 98%. The remaining 2% is mixed with the opposite waste generated.
The filter utilized in brine processing has helped obtain 98% restoration. [Photo: NASA]
The air revitalization system condenses moisture from the cabin air—primarily water vapor from sweat and exhalation—into liquid water. It directs the recovered water to the water processor meeting, which treats all of the collected water.
Treating recovered water
The water processor meeting’s remedy course of contains a number of steps.
First, all of the recovered water goes by filters to take away suspended particles reminiscent of mud. Then, a sequence of filters removes salts and among the natural contaminants, adopted by a chemical course of known as catalytic oxidation that makes use of warmth and oxygen to interrupt down the remaining natural compounds. The ultimate step is including iodine to the water to forestall microbial progress whereas it’s saved.
The output is potable water—typically cleaner than municipal faucet water on Earth.
Attending to Mars and past
To make human missions to Mars potential, NASA has estimated that spacecraft should reclaim at the very least 98% of the water used on board. Whereas self-sustaining journey to Mars continues to be a number of years away, the brand new brine processor on the ISS has elevated the water restoration fee sufficient that this 98% objective is now in attain. Nonetheless, extra work is required to develop a compact system that can be utilized in an area ship.
The journey to Mars is advanced, not simply due to the gap concerned, however as a result of Mars and Earth are always shifting of their respective orbits across the Solar.
The space between the 2 planets varies relying on their positions. On common, they’re about 140 million miles (225 million kilometers) aside, with the shortest theoretical method, when the 2 planets’ orbits carry them shut collectively, taking 33.9 million miles (54.6 million kilometers).
A typical crewed mission is anticipated to take about 9 months a technique. A round-trip mission to Mars, together with floor operations and return trajectory planning, might take round three years. As well as, launch home windows happen solely each 26 months, when Earth and Mars align favorably.
As NASA prepares to ship people on multiyear expeditions to the crimson planet, house businesses world wide proceed to give attention to enhancing propulsion and perfecting life help programs. Advances in closed-loop programs, robotic help and autonomous operations are all inching the dream of placing people on Mars nearer to actuality.
Berrin Tansel is a professor of civil and environmental engineering at Florida Worldwide College.
